A compact sensor specially designed for semi-active suspension control systems and attitude monitoring applications. Thanks to a configurable measurement range from 6 to 24 g, it can be installed both on chassis side and wheel side.
Requires engagement activity with the customer to individuate a correct installation position on the vehicle, compatible with thermal and vibrational sensor specifications, and calibrate/validate sensors outputs.
Attitude Estimation
Nominal: 5V, Range: 4.75V, 5.25V
IP 67
-40 C ... +85 C
5mA @ 5V
-40 C ... +85 C
±24 g ( ± 6 g or ±12 g available on request)
400, 200, 100 mV/g
0.05 ... [Vcc - 0.05] V
780 Hz
17g
Ratiometric
A full inertial measuring unit with 9 degrees of freedom and equipped with an Automotive 32bit Microcontroller, ASIL-B graded.
e-Shock Traction Control (eTCL) is one of the most accurate strategies of signal processing based on a data fusion algorithm specifically tuned for each application
